| Model specifications | Model | TCDL 6 | TCDL 11 / TCKC42 | TCDL 8 | TCKC62 | TCDL 11 | TCKC82 | TCDL 14 | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Technical parameters | Overall Dimension (L*W*H) | 3560*1520*1930 | 2900*1300*2000 | 4210*1520*1930 | 3600*1300*2000 | 5110*1520*1930 | 4400*1300*2000 | 5760*1520*1930 / 5200*1300*2000 | ||||
| Passengers Capacity | 6 | 4 | 8 | 6 | 11 | 8 | 14 / 10 | |||||
| Max.Speed(km/h) | 30 or Negotiatable | |||||||||||
| Max.Travelling Range(km) | 80~100 | |||||||||||
| Slope Climbing Capacity | 30% | |||||||||||
| Turning Radius(m) | 4.5 | 3.5 | 6.5 | 4.6 | 6.7 | 5.7 | 6.9 / 6.7 | |||||
| Minimum Ground Clearance (mm) | 300 | |||||||||||
| Brake Distance(m) | ≤5m | |||||||||||
| Wheel base(mm) | 1870 | 1700 | 2680 | 2400 | 3460 | 3100 | 4240 / 3850 | |||||
| Front/Rear Tread(mm) | Front 1300mm / Rear 1290mm | |||||||||||
| Weight(kg) | 720 | 560 | 740 | 620 | 980 | 710 | 1060 / 830 | |||||
| Electric system | Motor power (kw) | 3.5/4/5kw or customized | ||||||||||
| Electric Controller | Enpower Fully Intelligent Controller | |||||||||||
| Battery type | 6V 200AH /8V 150AH / 12V 100AH can choose | |||||||||||
| Charger | Intelligent high-frequency car charger | |||||||||||
| Charging time(h) | 8~10 | |||||||||||
| Charging input voltage | 220V/110V | |||||||||||
| Chassis system | Suspension | Front Torsion Beam Suspension+Integral rear axle high strength steel plate spring cartridge or customized | ||||||||||
| Brake system | Drum hydraulic brake, double-circuit hydraulic brake and parking brake device or customized | |||||||||||
| Steering | "Rack&Pinion" Steering | |||||||||||
| Motion transfer system | Continuously variable transmission | |||||||||||
| Drive mode | Rear drive | |||||||||||
| Exterior | Dashboard | Multi-function smart display (Bluetooth-radio-movie etc.) | ||||||||||
| Light | LED combined headlights, turn signals, combined rear taillights, brake lights and electric | |||||||||||
| Seat | Joint row seats (leather fabric + high resilience PU seats) | |||||||||||
| Body material | Steel frame + injection shell / ABS engineering plastic molded parts | |||||||||||
| Wheel | 10/12/14inch iron/aluminum wheels options | |||||||||||
| Tire | Road and off-road tire options | |||||||||||
A1: Generally, we pack our goods in containers by iron frame. If you have special requirements, we can follow.
A2: T/T 30% deposit, 70% balance before dispatch from factory.
A3: We can customize the logo for free as per your requests.
A4: Generally, it will take 7 to 15 days after receiving your advance payment. The specific delivery time depends on the items and the qty of your order.
A5: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
A6: The company will send a charger along with the electric car. Charging will finish automatically once the battery is full.
